Modular Monoliths

INFO

Wolverine's mantra is "low code ceremony," and the modular monolith approach comes with a mountain of temptation for a certain kind of software architect to try out a world of potentially harmful high ceremony coding techniques. The Wolverine team urges you to proceed with caution and allow simplicity to trump architectural theories about coupling between application modules.

Software development is still a young profession, and we are still figuring out the best ways to build systems, and that means the pendulum swings a bit back and forth on what the software community thinks is the best way to build large systems. We saw some poor results from the old monolithic applications of your as we got codebases with slow build times that made our IDE tools sluggish and were generally just hard to maintain over time.

Enter micro-services as an attempt to build software in smaller chunks where you might be able to be mostly working on smaller codebases with quicker builds, faster tests, and a much easier time upgrading technical infrastructure compared to monolithic applications. Of course there were some massive downsides with the whole distributed development thing, and our industry has become disillusioned.

TIP

We still think that Wolverine (and Marten) with its relentless focus on low ceremony code and strong support for asynchronous messaging makes the "Critter Stack" a great fit for micro-services -- and in some sense, a "modular monolith" can also be the first stage of a system architecture that ends up being micro-services after the best service boundaries are proven out before you try to pull modules into a separate service.

While micro-services as a concept might be parked in the trough of despair for awhile, the new thinking is to use a so called "Modular Monolith" approach that splits the difference between monoliths and micro-services.
The general idea is to start inside of a single process, but try to create more vertical decoupling between logical modules in the system as an alternative to both monoliths and micro-services.

The hope is that you can more easily reason about the code in a single module at a time compared to a monolith, but without having to tackle the extra deployment and management of micro-services upfront. Borrowing heavily from Milan Jovanović's writing on Modular Monoliths, the potential benefits are:

• Easier deployments than micro-services from simply having less to deploy
• Improved performance assuming that integration between modules is done in process
• Maybe easier debugging by just having one process to deal with, but asynchronous messaging even in process is never going to be the easiest thing in the world
• Hopefully, you have a relatively easy path to being able to separate modules into separate services later as the logical boundaries become clear. Arguably some of the worst outcomes of micro-services come from getting the service boundaries wrong upfront and creating very chatty interactions between different services. That can still happen with a modular monolith, but hopefully it's a lot easier to correct the boundaries later. We'll talk a lot more about this in the "Severability" section.
• The ability to adjust transaction boundaries to use native database transactions as it's valuable instead of only having eventual consistency

Another explicitly stated hope for modular monoliths is that you're able to better iterate between modules to find the most effective boundaries between logical modules before severing modules into separate services later when that is beneficial.

Important Wolverine Settings

Wolverine was admittedly conceived of and optimized for a world where micro-service architecture was the hot topic, and we've had to scramble a little bit as a community lately to make Wolverine be more suitable for how users now want to use Wolverine for modular monoliths. To avoid making breaking changes, we've had to put some modular monolith-friendly features behind configuration settings so as not to break existing users.

Specifically, Wolverine "classic" has two conceptual problems for modular monoliths with its original model:

1. If you have multiple message handlers for the same message type, Wolverine combines these handlers into one logical message handler and one logical transaction
2. Messages in its transactional inbox are identified by only the message id. That's worked great until folks start wanting to receive the same message from an external broker, but handled separately by different handlers receiving the same message from different queues or subscriptions or topics depending on the external transport. This is shown below:

Both of these behaviors can be changed in your application by setting these two flags shown below:

var builder = Host.CreateApplicationBuilder();

// It's not important that it's Marten here, just that if you have
// *any* message persistence configured for the transactional inbox/outbox
// support, it's impacted by the MessageIdentity setting
builder.Services.AddMarten(opts =>
    {
        var connectionString = builder.Configuration.GetConnectionString("marten");
        opts.Connection(connectionString);
    })

    // This line of code is adding a PostgreSQL backed transactional inbox/outbox
    // integration using the same database as what Marten is using
    .IntegrateWithWolverine();

builder.UseWolverine(opts =>
{
    // Tell Wolverine that when you have more than one handler for the same
    // message type, they should be executed separately and automatically
    // "stuck" to separate local queues
    opts.MultipleHandlerBehavior = MultipleHandlerBehavior.Separated;

    // *If* you may be using external message brokers in such a way that they
    // are "fanning out" a single message sent from an upstream system into
    // multiple listeners within the same Wolverine process, you'll want to make
    // this setting to tell Wolverine to treat that as completely different messages
    // instead of failing by idempotency checks
    opts.Durability.MessageIdentity = MessageIdentity.IdAndDestination;

    // Not 100% necessary for "modular monoliths", but this makes the Wolverine durable
    // inbox/outbox feature a lot easier to use and DRYs up your message handlers
    opts.Policies.AutoApplyTransactions();
});

^{snippet source | anchor}

See Message Identity and Multiple Handlers for the Same Message Type for more detail.

The MultipleHandlerBehavior.Separated setting is meant for an increasingly common scenario shown below where you want to take completely separate actions on an event message by separate logical modules published by an upstream handler:

By using the MultipleHandlerBehavior.Separated setting, we're directing Wolverine to track any OrderPlaced event message completely separately for each handler. By default this would be publishing the event message to two completely separate local, in process queues inside the Wolverine application. By publishing to separate queues, you also get:

• Independent transactions for each handler -- assuming that you're using Wolverine transactional middleware anyway
• Separate retry loops and potentially different error handling policies for the message to each handler
• The ability to mix and match durable vs lighter weight "fire and forget" (Buffered in Wolverine parlance) semantics for different handlers
• Granular tracing and logging on the handlers

Splitting Your System into Separate Assemblies

INFO

The technical leader of Wolverine has a decades old loathing of the Onion Architecture and now the current Clean Architecture fad. While it's perfectly possible to spread a Wolverine application out over separate assemblies, we'd urge you to keep your project structure as simple as possible and not automatically incur extra code ceremony by trying to use separate projects just to enforce coupling rules.

To be honest, the Wolverine team would recommend just keeping your modules segregated in separate namespaces until the initial system gets subjectively big enough that you'd want them separated.

Do note that Wolverine identifies message types by default by the message type's full type name ([.NET namespace].[type name]). You can always override that explicitly through the [MessageIdentity] attribute, but you might try to not have to move message types around in the namespace structure. The only real impact is on messages that are in flight in either external message queues or message persistence, so it does no harm to change namespaces if you are only in development and have not yet deployed to production.

For handler or HTTP endpoint discovery, you can tell Wolverine to look in additional assemblies. See Assembly Discovery for more information. As for pre-generated code with Wolverine, the least friction and idiomatic approach is to just have all Wolverine-generated code placed in the entry assembly. That can be overridden if you have to by setting the "Application Assembly" as shown in the Assembly Discovery section in the documentation.

In Process vs External Messaging

TIP

Just to be clear, we pretty well never recommend calling IMessageBus.InvokeAsync() inline in any message handler to another message handler. For the most part, we think you can build much more robust and resilient systems by leveraging asynchronous messaging. Using Wolverine as a "Mediator" in MVC controllers, Minimal API functions, or maybe Hot Chocolate mutations is an exception case that we fully support. We think this advice applies to any mediator tool and the pattern in general as well.

By and large, the Wolverine community will recommend you do most communication between modules through some sort of asynchronous messaging, either locally in process or through external message brokers. Asynchronous messaging will help you keep your modules decoupled, and often leads to much more resilient systems as your modules aren't "temporally" coupled and you utilize retry or other error handling policies independently on downstream queues.

You can communicate do any mix of in process messaging and messaging through external messaging brokers like Rabbit MQ or Azure Service Bus. Let's start with just using local, in process queueing with Wolverine between your modules as shown below:

Now, let's say that you want to publish an OrderPlaced event message from the successful processing of a PlaceOrder command in a message handler something like this:

public static OrderPlaced Handle(PlaceOrder command)
{
    // actually do stuff to place a new order...

    // Returning this from the method will "cascade" this
    // object as a message. Essentially just publishing
    // this as a message to any active subscribers in the
    // Wolverine system
    return new OrderPlaced(command.OrderId);
}

and assuming that there's at least one known message handler in your application for the OrderPlaced event:

public static class OrderPlacedHandler
{
    public static void Handle(OrderPlaced @event)
        => Debug.WriteLine("got a new order " + @event.OrderId);
}

then Wolverine -- by default -- will happily publish OrderPlaced through a local queue named after the full type name of the OrderPlaced event. You can even make these local queues durable by having them effectively backed by your application's Wolverine message storage (the transactional inbox to be precise), with a couple different approaches to do this shown below:

using var host = await Host.CreateDefaultBuilder()
    .UseWolverine(opts =>
    {
        opts.Policies.UseDurableLocalQueues();

        // or

        opts.LocalQueue("important").UseDurableInbox();

        // or conventionally, make the local queues for messages in a certain namespace
        // be durable
        opts.Policies.ConfigureConventionalLocalRouting().CustomizeQueues((type, queue) =>
        {
            if (type.IsInNamespace("MyApp.Commands.Durable"))
            {
                queue.UseDurableInbox();
            }
        });
    }).StartAsync();

^{snippet source | anchor}

Using local queues for communication is a simple way to get started, requires less deployment overhead in general, and is potentially faster than using external message brokers due to the in process communication.

INFO

If you are using durable local queues, Wolverine is still serializing the message to put it in the durable transactional inbox storage, but the actual message object is used as is when it's passed into the local queue.

Alternatively, you could instead choose to do all intra-module communication through external message brokers as shown below:

Picking Azure Service Bus for our sample, you could use conventional message routing to publish all messages through your system through Azure Service Bus queues like this:

var builder = Host.CreateApplicationBuilder();
builder.UseWolverine(opts =>
{
    // Turn *off* the conventional local routing so that
    // the messages that this application handles still go
    // through the external Azure Service Bus broker
    opts.Policies.DisableConventionalLocalRouting();

    // One way or another, you're probably pulling the Azure Service Bus
    // connection string out of configuration
    var azureServiceBusConnectionString = builder
        .Configuration
        .GetConnectionString("azure-service-bus");

    // Connect to the broker in the simplest possible way
    opts.UseAzureServiceBus(azureServiceBusConnectionString).AutoProvision()
        .UseConventionalRouting();
});

using var host = builder.Build();
await host.StartAsync();

^{snippet source | anchor}

By using external queues instead of local queues, you are:

• Potentially getting smoother load balanced workloads between running nodes of a clustered application
• Reducing memory pressure in your applications, especially if there's any risk of a queue getting backed up and growing large in memory

And of course, Wolverine has a wealth of ways to customize message routing for sequencing, grouping, and parallelization. As well as allowing you to mix and match local and external broker messaging or durable and non-durable messaging all within the same application.

See the recently updated documentation on Message Routing in Wolverine to learn more.

Eventual Consistency between Modules

We (the Wolverine team) are loathe to recommend using eventual consistency between modules if you don't have to. It's always going to be technically simpler to just make all the related changes in a single database transaction. It'll definitely be easier to test and troubleshoot problems if you don't use eventual consistency. Not to mention the challenges with user interfaces getting the right updates and possibly dealing with stale data.

To be clear though, we strongly recommend using asynchronous communication between modules and recommend against using IMessageBus.InvokeAsync() inline in most cases to synchronously interact with any other module from a message handler. We think your most common decision is:

• Would it be easier in the end to combine functionality into one larger module to utilize transactional integrity and avoid the need for eventual consistency through asynchronous messaging
• Or is there a real justification for publishing event messages to other modules to take action later?

Assuming that you do opt for eventual consistency, Wolverine makes that quite simple. Just make sure that you are using durable endpoints for communication between any two or more actions that are involved for the implied eventual consistency transactional boundary so that the work does not get lost even in the face of transient errors or unexpected system shutdowns.

TIP

Look, MediatR is an almost dominant tool in the .NET ecosystem right now, but it doesn't come with any kind of built in transactional inbox/outbox support that you need to make asynchronous message passing be resilient. See MediatR to Wolverine for information about switching to Wolverine from MediatR.

Test Automation Support

INFO

As a community, we'll most assuredly need to add more convenient API signatures to the tracked sessions specifically to deal with the new usages coming out of modular monolith strategies, but we're first waiting for feedback from real projects on what would be helpful before doing that.

Wolverine's Tracked Sessions feature is purpose built for test automation support when you want to write tests that might span the activity of more than one message being handled. Consider the case of testing the handling of a PlaceOrder command that in turn publishes an OrderPlaced event message that is handled by one or more other handlers within your modular monolith system. If you want to write a reliable test that spans the activities of all of these messages, you can utilize Wolverine's "tracked sessions" like this:

// Personally, I prefer to reuse the IHost between tests and
// do something to clear off any dirty state, but other folks
// will spin up an IHost per test to maybe get better test parallelization
public static async Task run_end_to_end(IHost host)
{
    var placeOrder = new PlaceOrder("111", "222", 1000);

    // This would be the "act" part of your arrange/act/assert
    // test structure
    var tracked = await host.InvokeMessageAndWaitAsync(placeOrder);

    // proceed to test the outcome of handling the original command *and*
    // any subsequent domain events that are published from the original
    // command handler
}

^{snippet source | anchor}

In the code sample above, the InvokeAndMessageAndWaitAsync() method puts the Wolverine runtime into a "tracked" mode where it's able to "know" when all in flight work is complete and allow your integration testing to be reliable by waiting until all cascaded messages are also complete (and yes, it works recursively). One of the challenges of testing asynchronous code is not doing the assert phase of the test until the act part is really complete, and "tracked sessions" are Wolverine's answer to that problem.

Just to note that there are more options you'll maybe need to use with modular monoliths, this version of tracking activity also includes any outstanding work from messages that are sent to external brokers:

public static async Task run_end_to_end_with_external_transports(IHost host)
{
    var placeOrder = new PlaceOrder("111", "222", 1000);

    // This would be the "act" part of your arrange/act/assert
    // test structure
    var tracked = await host
        .TrackActivity()

        // Direct Wolverine to also track activity coming and going from
        // external brokers
        .IncludeExternalTransports()

        // You'll sadly need to do this sometimes
        .Timeout(30.Seconds())

        // You *might* have to do this as well to make
        // your tests more reliable in the face of async messaging
        .WaitForMessageToBeReceivedAt<OrderPlaced>(host)

        .InvokeMessageAndWaitAsync(placeOrder);

    // proceed to test the outcome of handling the original command *and*
    // any subsequent domain events that are published from the original
    // command handler
}

^{snippet source | anchor}

And to test the invocation of an event message to a specific handler, we can still do that by sending the message to a specific local queue:

public static async Task test_specific_handler(IHost host)
{
    // We're not thrilled with this usage and it's possible there's
    // syntactic sugar additions to the API soon
    await host.ExecuteAndWaitAsync(
        c => c.EndpointFor("local queue name").SendAsync(new OrderPlaced("111")).AsTask());
}

^{snippet source | anchor}

With EF Core

TIP

There is no way to utilize more than one DbContext type in a single handler while using the Wolverine transactional middleware. You can certainly do that, just with explicit code.

For EF Core usage, we would recommend using separate DbContext types for different modules that all target a separate database schema, but still land in the same physical database. This may change soon, but for right now, Wolverine only supports transactional inbox/outbox usage with a single database with EF Core.

To maintain "severability" of modules to separate services later, you probably want to avoid making foreign key relationships in your database between tables owned by different modules. And of course, by and large only use one DbContext type in the code for a single module. Or maybe more accurately, only one module should use one DbContext.

With Marten

Marten plays pretty well with modular monoliths. For the most part, you can happily just stick all your documents in the same database schema and use the same IDocumentStore if you want while still being able to migrate some of those documents later if you choose to sever some modules over into a separate service. With the event sourcing though, all the events for different aggregate types or stream types all go into the same events table. While it's not impossible to separate the events through database scripts if you want to move a module into a separate service later, it's probably going to be easier if you use Marten's separate document store feature.

Wolverine has direct support for Marten's separate or "ancillary" stores that still enables the usage of all Wolverine + Marten integrations. There is currently a limitation that there is only one physical database that shares the Wolverine message storage for the transactional inbox/outbox across all modules.

Also note that the Wolverine + Marten "Critter Stack" combination is a great fit for "Event Driven Architecture" approaches where you depend on reliably publishing event messages to interested listeners in your application -- which is essentially how a lot of folks want to build their modular monoliths.

See the introduction to event subscriptions from Marten.

Observability

If you're going to opt into using asynchronous message passing within your application between modules or even just really using any kind of asynchronous messaging within a Wolverine application, we very strongly recommending using some sort of OpenTelemetry (Otel) compatible monitoring tool (I would think that every monitoring tool supports Otel by now). Wolverine emits Otel activity spans for all message processing as well as just about any kind of relevant event within a Wolverine application.

See the Wolverine Otel support for more information.
